Diamond Pro Straight Face

8 x 18 x 12

With greater square footage per unit than the popular  Diamond Pro^® retaining wall is an ideal choice for large projects. Architects, engineers, and contractors choose Diamond Pro^® to create flexible, cost-effective solutions for a broad range of large retaining wall projects.

Features & Benefits:

• Rear-lip locator
• Large cores for ease in handling
• Matching corner and cap for a seamless appearance
• Gravity walls can be built up to 4 ft high, including buried course with a 7.1° batter
• Walls in excess of 50 ft high have been built with Diamond Pro when combined with geosynthetic reinforcement
• Minimum outside radius, measured from the top course to the front of the units: 4 ft
• Minimum inside radius, measured on the base course to the front of the units: 6 ft
